MiniCut 300 – For Condenser and Chillers
Key Features
The MiniCut 600 is recommended for use in cutting tubes within condensers, chillers and similar vessels with non-ferrous tubes. The machine can cut 1” x 16 BWG brass tubes in just a few seconds. This machine is equipped with lever feed handle as standard.
Main technical data
| Main unit | MiniCut 300 | |
| Cutters | Go to datasheet. | |
| Cutting range | Up to 1” OD | Up to 25,4 mm |
| Material | non-ferrous | |
| Cutting method | one cutting bit | |
| Power | 1,3 Hp | |
| Free speed | 300 Rpm | |
| Torque | 18 Ft.Lbs | 24 Nm |
| Air consumption | 55 cfm | 1,3 m3/min |
| Width without head | 2,32” | 59 mm |
| Height | 13,1” | 335 mm |
| Weight | 9 Lbs | 4,5 kg |
